FAAC 740 Kit

Technical Specifications:

• Power supply: 230V AC 50(60) Hz
• Absorbed power: 350W
• Absorbed current: 1.5A
• Traction and thrust force: 45N
• Motor rotation speed: 1400rpm
• Reduction ration: 1:25
• Max gate weight: 500kg
• Max gate length: 9m
• Gate speed: 12m/min (pinion Z16)
• Protection class: IP44
• Limit switch: Magnetic / Inductive
• Thermal protection on motor winding: 140°C
• Operating ambient temperature: -20°C to +55°C
• Dimensions: 295 x 225 x 325
• Two years warranty

Kit Contains:

• 1x 740 E Z16 Gearmotor
• 4x Strengthened Nylon Rack
• 2x 433 RC 4-button Remote
• 1x 1 Channel 433 RC Receiver Card

Manual Download

*PICK UP ONLY*
